This Goodyear rolling lobe air spring is engineered to provide superior suspension performance with a composite bottom plate and precise fit. With a maximum height of 18.9" and a minimum height of 7.9", it features a 9" top plate diameter and a 10.2" bottom plate diameter. The air spring is designed with a parallel alignment of the bottom plate and a single bottom plate stud for reliable performance in demanding applications. It is equipped with a bumper for added protection and durability.
-
Bellow Type: Rolling Lobe
-
Bellows Part Number: 566-24-3-171
-
Bottom Plate / Piston Type: C - Composite
-
Top Plate Diameter: 9 in
-
Top Plate Hole / Stud Qty: 2
-
Bottom Plate Diameter: 10.2 in
-
Bottom Plate Alignment: Parallel
-
Bottom Plate Hole / Stud Qty: 1
-
Max Height: 18.9 in
-
Min Height: 7.9 in
-
Top Plate C to C Diameter: 5.5 in
-
Bottom Plate C to C Diameter: N/A
-
Bottom Plate Part Number: 566-20-7-425
-
Bumper: Yes
-
Bracket: N/A
